| Stock | Delivery time |
|---|---|
| 4 | On workingdays before 12:00 ordered, shipped the same day |
| Quantity | Per piece |
|---|---|
| 1+ | € 30,6900 |
| 2+ | € 20,1818 |
| 3+ | € 19,6694 |
| 5+ | € 17,4711 |
| 10+ | € 19,7727 |
| 25+ | € 18,5331 |
| 50+ | € 18,1198 |
| 100+ | € 15,2273 |
This PTFE O-Ring has a diameter of mm and is White in color. The hardness of this Back-up Ring 156.4x165x1.9 - PTFE - Closed - 51 Shore D - White - ORS276242 is 51 Shore D. Alternative names for the compound are , and it is commonly produced by . The O-Ring is typically used in and has an operating temperature range from -200 to 260. O-Rings 6534158 are referred to as 276242 and have a DIN 3771 size of . This item is equivalent to and has an approval. The chemical name of this O-Ring is Polytetrafluoronthylene.
| In stock | Yes, 4 pcs |
| Article number | 276242 |
| ID (Inner diameter) | 156.4 |
| W (Snoer Dikte) | 4.3 |
| Export specifications | |
| Country of Origin | IT |
| Customs Code | 39269097 |
| General Specifications | |
| H (Height) | 1.9 |
| OD (Outer Diameter) | 165 |
| Material | PTFE |
| Color | White |
| Compound Number | 169901381 |
| Dimensions | 156.4x165x1.9 |
| Hardness | 51 Shore D |
| Variant | Closed |
| Technical Specifications | |
| Chemical Name | Polytetrafluoronthylene |
| Specific Gravity | 2,16 (±0,02) |
| Temperature Max | 260 |
| Temperature Min | -200 |
| Also found under | |
| Back-up Rings | Back-up rings PTFE | |
